LinearLinear
Linear2时间：2022-02-07 22:05:47 浏览次数：
| 产品型号 model： | Linear2 |
| 产品类型 Product Type： | 远程点生源Remote point source |
| 频率响应Frequency response: | 50HZ-22KHZ |
| 组件 Components: | 1x12"Low +1"High coaxial 1x3.5"Mid 1x+1.75"High |
| 中频 Mid（Coaxial neodymium compression drive）： | 3.5" DDP(coaxial neodymium compression drive) |
| 高频 High： | Precise and transparent 1x+1.75"high frequency driver |
| 中频 Mid/ AES/ peak: | 150W/1000W |
| 高频 High AES/ peak: | 1x80W/320W |
| 主方向远程指向 The main direction is remote pointing: | coaxial 1x3.5"Mid 1x+1.75"High/Horizontal 100°vertical 10° |
| 中/高频1W/1m Sensitivity mid / high 1W / 1m: | 118dB |
| 最大声压级 Maximum peak SPL: | 148dB |
| 侧活动中程指向 Side activity mid-pointing： | 1x+1"High/Horizontal 100°vertical 10° |
| 低频 Low AES/ peak: | 1400W/2800W |
| 高频 High AES/ peak: | 1x60W/240W |
| 灵敏度1W/1m Sensitivity low 1W / 1m: | 93dB |
| 分频方式 Crossover mode： | 1+1-/2+2- Passive built-in crossover |
| 输入接线方式 Enter the wiring method | INPUT 1+1- Low+High 8Ω / 2+2- Mid+High 8Ω |
| 箱体板材 Box plate： | Baltic birch plywood |
| 箱体五金 Box hardware： | Black stainless steel |
| 防水性能 Waterproof： | IP55 |
| 安装吊挂方式Install hanging mode： | M10x10 |
| 箱体外观Polyurea coating (water resistant)： | Polyurea coating (water resistant) |
| 规格尺寸 Dimensions： | W432mmxH700mmxD520mm |
| 净重量 Net: | 36.2KG |
